HQ100H Hybrid Power System
Configuration
Simple configuration of one stage centrifugal compressor, one stage centripetal turbine, and an annular reflux combustion chamber
Characteristics
| Maximum Continuous Power kw | 120 | 150 |
|
Maximum Fuel Consumption Rate kg/(kw.h) |
0.55 | 0.49 |
| Ceiling m | 4000 | 6000 |
| Dry Weight kg | 60 | 75 |
| mmSize(diameter/length) mm | 412/747 |
412/740 |
Applications
Electric-Driven Vertical Takeoff and Landing Vehicle (E-VTOL)
